质量能量密度300瓦时/公斤
体积能量密度700瓦时/升
100C持续放电,温升控制在40℃以内
80℃高温持续循环200周,85℃储存48小时
通过针刺、重物冲击等安全性测试
产品编号:36AQ500-03
标称电压:10.8V
标称容量:9900mAh
电池尺寸:203*57*19.5mm (Max)
充电温度:0~45℃
放电温度:-40 ~ 65 ℃
应用领域:Instrumentation
浏览次数:869次
Product number: 36AQ500-03
Cell model: 18650/3350mah /3.6V
Specification: 18650-3S3P-9.9 AH-10.8V
Product size: 203*57*19.5mm (Max)
Nominal voltage: 10.8V
Nominal capacity: 9.9Ah
Charging voltage: 12.6V
Charging current: 3A
Discharge current: 3A
Discharge cut-off voltage: 7.5V
Product internal resistance: ≤180mΩ
Battery weight: ≤ 520G
Charging temperature: 0 ~ 45℃
Discharge temperature: -40 ~ 65 ℃
Storage temperature: -40 to +45 ° C (less than 1 month) -20 to 35 ° C (less than 3 months); -20~+25℃ (less than 12 months)
Battery case: PVC process
Lithium battery protection: short circuit protection, over charge protection, over discharge protection, over current protection, over temperature protection, etc.
Application: Instrumentation
Product Features
1.Plastic shell is simple, reliable and easy to install.
2.SMBUS communication protocol
3.Output terminal: Adopt the output mode of GB UL wire to increase conductive reliability.
4.Battery protection management: Adopt imported well-known protection chips with good stability, high precision monitoring and precise control, to eliminate safety risks to the maximum.
5.The battery pack is safe, has good discharge performance and long cycle life.
6.The battery pack has a long cycle life and conforms to the values of low-carbon, energy saving and environmental protection.
